Adult, Pediatric & Infant Ventilator

Mechanical ventilator that provides invasive and non-invasive ventilation for adult and pediatric patients, and for neonatal patients (Optional).

Get A Quote Request A Demo

This product is currently out of stock and unavailable.


  • Neonatal ventilation is available as option (installed or retrofit)
  • 12.1″ TFT- LED colour touchscreen display to view waveforms & loops simultaneously
  • Tidal Volume correction according to BTPS leak compensation in all modes
  • Altitude and circuit compliance compensation with Leakage Compensation possible in all modes
  • Advanced modes like APRV, MMV+ Pressure Support, PSV+ assured Volume
  • PRVC – Pressure Regulated Volume Control, SIMV (PRVC)+ PSV, VSV
  • Selectable apnea back up ventilation (Volume or Pressure type)
  • 72 hours trend display
  • User adjustable ideal body weight factor
  • Integrated nebulizer (Volume compensated & Inspiratory Synchronize)
  • Advanced Lung Mechanism calculations: Auto-PEEP and trapped Volume, WOBi, Exp. Time Constant, P/V Flex Monitoring, Slow Vital Capacity,Pi Max (NIF)
  • Suction % O2 for suction sequence with variable FiO2 Non-Invasive Ventilation available


  • Neonatal Ventilation with special modes available
  • AVA – Adaptive Ventilatory Assistance
  • SBT – Spontaneous Breathing Trial and Stress Index
  • Oxygen Index PaFi
  • High Flow Oxygen Therapy (HFOT/ HFNC)
  • Capnography (Mainstream) – Curves of CO2 / Time and 2 Volumetric Capnography (CO2 / VT), Measurements of
    EtCO2 Alveolar Ventilation, Dead Space, CO2 Elimination  (VCO2 ), VD / VT Ratio, CO2 expired volume (VTCO2 )
