ERG 910 plus / ERG 911 plus

Quiet, compact, configurable

The bike ergometers ERG 910 plus and ERG 911 plus were developed for use in the cardiology sector.

The devices are used to perform defined exercises during ergometric examinations and therapeutic applications. All major exercise data (such as blood pressure, heart rate, pedalling rate, colour-coded information concerning correct pedalling rate) is displayed in a compact format.

Get A Quote Request A Demo

This product is currently out of stock and unavailable.

Speak with an Expert

Description
Additional information

Features

Two operational modes:
- Remote operation with a master device (ECG, PC, …)
- Standalone operation with either a user-definable step protocol or manual load control
Display rotatable (180°), handlebar adjustable (360°)
Bluetooth and RS-232 connection
Ergonomic sitting position for patients measuring between 1.40 m and 2.10 m
Patient weight up to 160 kg
Low frame for easy access
Maintenance-free and almost noiseless thanks to belt drive
Stable steel tube construction, minimal use of floor space
Optimal gyrating mass for a pleasant pedalling sensation
Mains connection 230 V

Options and accessories

SpO₂ measurement with finger or ear clip
Blood pressure measurement with QRS trigger
Mains connection 115 V
Child saddle and pedals for patients from 1.20 m
With stabiliser for patients weighing up to 200 kg

ERG 910 plus

Load range 20 – 500 watts, optional 20 – 999 watts

ERG 911 plus

Load range 20 – 999 watts
Handle bar height adjustable
Saddle height electrically adjustable (optional)

SCHILLER reserves the right to make changes in design, specifications and features shown, or discontinue the product described at any time without notice or obligation. In representative. Device availability in your market is subject to regulatory approval

ETM Sport

The first automated ECG interpretation module designed for athletes

The distinction between physiological and pathological ECG variations in athletes represents a major challenge.

SCHILLER’s ETM Sport, when used in sport aptitude tests, allows the number of false-positive results to be reduced while the sensitivity to detect heart disease remains unchanged.
ETM Sport is based on the Seattle Criteria.

High load precision

Quiet mechanism even at high speed

Low frame for easy mounting

Maintenance-free

Downloads

Download Brochure
