CARDIOVIT CS-104 With SpiroScout SP plus

Ultrasound Spirometry

Ultrasound Spirometry in combination with SCHILLER ECG devices

The SpiroScout SP plus helps to make your office more efficient by adding spirometry measurements to your existing compatible SCHILLER ECG device. You’ll enjoy all the benefits of a full-featured ECG and spirometer with data organised in the same fashion, facilitating data management.
The SpiroScout SP plus incorporates an ultrasound flow sensor to measure the flow of air into and out of the patient’s lungs. There are no moving parts, no screens to catch sputum and no disposables to calibrate.

Get A Quote Request A Demo

This product is currently out of stock and unavailable.

Speak with an Expert

Description
Additional information

Features

High-precision spirometry due to direct flow measurement
Sensor is not influenced by humidity, barometric pressure and contamination
Maintenance-free
Used with ScoutTubes, the hygienic mouthpiece for single-patient use
The ScoutTubes are climate-neutral. Please check our declaration by entering tracking number 01-20-162037 in the search bar on www.myclimate.org
Connected via USB connector

SCHILLER reserves the right to make changes in design, specifications and features shown, or discontinue the product described at any time without notice or obligation. In representative. Device availability in your market is subject to regulatory approval

Ultrasound technology

Extremely high accuracy for low flows

Moisture resistant

No cleaning and maintenance needed

Downloads

Download Brochure
