Features
- Featuring a large 10.4-inch touch screen and an adjustable display for an ideal viewing angle without moving the machine, this device offers intuitive and enhanced control
- Double-Tube Mechanical Flowmeter with Backlight, ideal for Endoscopic Surgery and More
- Compact, Versatile & Ergonomic design ensures seamless workflow and precise navigation for the surgical procedures.
- Standard sets of Ventilation Modes (IPPV, PCV and Manual, SIMV-VC, SIMV-PC, PS/CPAP) with a minimum tidal volume of 20ml in volume control mode (IPPV)
- Advanced Ventilation Mode like PCV-VG is ideal for supporting patients during all types of moderate to severe surgical procedures
- Uniformly Heated alluminium alloy Breathing system to avoid condensation during low-flow anaesthesia or longer operative procedures
- Featuring a modern design made from rust free aluminum alloy breathing system
- A fast-release function via the APL valve to enhance resuscitation efficiency post-surgery
- Equipped with a differential pressure flow sensor that requires no consumables and a sensitive, ultra-light ceramic one-way valve diaphragm, which is optimized for the respiratory management of pediatric anesthesia
- Equiped with Compliance, leak & fresh gas flow compensation
- CO2 bypass feature
- ACGO – Standard Auxiliary Common Gas Outlet
- Standard Auxiliary O2 gas outlet
Optional & Upgradeable Features
- AGSS – Active: Optional, Passive: Standard
- Multiple Anaesthetic Gas Monitoring (AGM) or CO2 with mainstream or side stream option
- Vaporizers for all AA (Halo, ISO, SEVO & DES) featuring various filling options and supporting Selectatec mounting for up to 2 units
SCHILLER reserves the right to make changes in design, specifications and features shown, or discontinue the product described at any time without notice or obligation. In representative. Device availability in your market is subject to regulatory approval
